Glarex Projection Screen breve descrizione!   Nessun commento

Inserito alle 2:34 pm in Microscopia

Glarex Projector Screen

L’ accessorio che è visibile nelle foto che seguono, non è strettamente legato ad un’esigenza particolare in quanto ormai soppiantato da telecamere di ogni tipo, m, a allettato anche dal prezzo non molto alto (intorno a 70€ sul web), ho voluto acquistarlo anche come complemento per il mio Zeiss photomicroscope III….….assicuro che l’impatto visivo è davvero d’effetto!inoltre quando non si ha a disposizione una telecamera, oppure  si è un pò svogliati a montare e rimontare la stessa, o ancora quando particolari fonti luminose come L’UV vengono utilizzate, allora uno strumento del genere può tornare utile!

Il pezzo  presenta  dimensioni e peso abbastanza generosi ma non tanto da impensierire la testa e il braccio del vecchio zeiss, ma la vera chicca è   un motore da 1,9v montato  nella parte superiore; questa è una novità rispetto ai modelli di proiezione precedenti.

Tale motore, tramite un meccanismo, ruota uno dei due vetri smerigliati (quello posteriore) in modo oscillatorio in modo tale che la grana della smerigliatura (benchè finissima) non sia assolutamente visibile; ciò rende possibile l’osservazione anche dei più minuti particolari del campione.

The item  visible in the following pics , is not strictly tied to a particular need because now  cameras of any kind replaced it , but, lured by the price , not very high (around 70 € on the web), I wanted purchase it as a supplement for my Zeiss photomicroscope III! assure that the visual impact is really impressive!

when you have not a camera, or you don’t like  assemble and disassemble the same, or where special light sources are used as the UV, then this screen can help you.The piece presents fairly generous in size and weight but not enough to worry the head and arm of the old Zeiss, but the real gem is a 1.9 V motor mounted on the top, this is a new compared to the previous projection models.

This engine, by a mechanism, move one of the two frosted glass (rear one) to oscillatory so that the texture of the grinding (though thin) is  totally invisible, which makes it possible to observe even the most minute details of the sample.

glarex-microVista generale – general view glarex-alto motore - motormisure-front misure – sizetasform trasformatore – transformertrasform glarex-diatom vista dei campioni – samples viewcampione





NOTE:

L’interruttore al momento dell’arrivo, non funzionava a dovere, cioè a volte si accendeva altre no; convinto ormai che fosse da sostituire ho provato a smontarlo e nell’aprirlo, ho trovato all’interno tutto un sistema meccanico costituito da piccoli pezzi e due bilanceri che, mossi dalla leva dell’interruttore venivano spinti contro le alette metalliche collegate ai fili (immagine in basso); il problema???   ossidazione nelle superfici di contatto.

Ho quindi provveduto alla loro pulitura con dello Xilolo (ATTENZIONE: prodotto cancerogeno, si eviti di respirarne i vapori) e al riassemblaggio; ora va che è una bomba. Un’ultima cosa: nello smontare l’ interruttore si faccia molta attenzione a non perdere sia la molla che i 4 pezzetti di materiale isolante che vanno al di sopra delle staffette conduttrici.

When i recived package switch did not working good. My idea was to replace it, but when i opened it i found  the problem..ossidation in surfaces of contact (pics below)…so i polished the surfaces whit Xilolo (ATTENTION: carcinogens product, avoid to breathe fumes) and assempled again all parts.Now it work very very good. If you want to disassemble the switch, please make attentino to not loose the spring and small pieces of insulator material.

interruttoreinterruttore smontato – disassembled switch

Arturo Agostino

Scritto da admin il 15 settembre 2010
